Запчасти Bobcat BL275 HYDRAULIC CIRCUITRY Filter HYDRAULIC SYSTEM

1

6960724

FILTER W/Ref. 2,4,6,7,8,9,10, 13

2

6969402

COVER W/Ref. 3, 12

3

SEAL NLA

4

6969403

COMPONENT-FILTER W/Ref. 3, 5, 11

5

SPRING NLA

6

6967206

INSERT

7

6969404

COMPONENT-FILTER

8

FILTER NLA

9

SEAL NLA

10

6967207

SENSOR

11

BODY NLA

12

COVER NLA

13

SEAL NLA

14

6969412

KIT, SEAL W/Ref. 3,9
