Запчасти Bobcat BAP185 INST/CONT PNL ASSEMBLY MAIN FRAME

1

IR54749601

FRAME WW INSTR Panel

2

IR22171680

INSTR PANEL Instrument - Was IR54749619 - A

3

IR54766845

DECAL WW INSTR Panel

4

IR54766704

METER Electronic Hour

5

IR22054159

NUT Plastic 4-40

6

IR22127385

IGNITION Ignition

7

IR35604065

GAUGE 150 PSI Pressure

8

IR95935599

COUPLING STD 1/8 NPT x .75

9

IR35370386

ELBOW 1/8 NPT x 3/8 Tube

10

IR22054167

KEY Removable Ingnition

11

IR54774104

KEY Non-Removable Ignition

12

IR22107478

HINGE, SPRING, CNTRL PNL Control Panel - Was IR36890085 - A

13

IR54482500

DOOR Instrument Panel (STD. Paint)

13

IR54729199

DOOR Instrument Panel (Special Paint)

14

IR22070494

SCREW Plastic Tapping

15

IR54721212

RIVET 3/16 Aluminum

16

IR54721220

RIVET 3/16 Aluminum
