1
000350-20Q
WASHER
2
01598.2
Screw
3
01612.1
Screw
4
008372-01B
ELBOW PIECE
5
008372-34M
UNION
6
010370-94B
ELBOW PIECE
7
11689.7
Washer
8
014375-30H
UNION
9
7186826
COUPLER, QUICK FEMALE Was 95993.2 - A
10
022375-04U
UNION
11
7225156
FITTING, HYD Was 022375-06W - A
12
022375-28V
UNION
13
1CM650
SCREW Was 48829.6 - A
14
01681.6
Nut Was 51851.4 - B
15
56029.2
Plug
16
65614.0
Union
17
68566.9
Screw
18
70225.8
Hose
19
70225.8
Hose
20
72294.2
Elbow union
21
78743.2
Drain plug
22
79160.8
Screw
23
94574.1
Washer
24
7186826
COUPLER, QUICK FEMALE Was 95993.2 - A
25
7225159
COUPLER, HYD Was 95994.0 - A
26
7225160
CAP, COUPLER Was 96513.7 - A
27
7225161
CAP, COUPLER Was 96514.5 - A
28
96589.7
Wire harness
29
98360.1
Union
30
100345-09A
NUT
31
100375-38S
UNION
32
100375-44Z
REDUCER 1.1/16JIC 7/8JIC (20-16)
33
100375-52H
UNION
34
6910275
Hose
35
6910517
PROTECTOR
36
6911079
HYDRAULIC BLOCK
37
6911164
HOSE
38
6911845
SOLENOID 2-2
39
6922045
HOSE
40
6922991
SUPPORT
41
6927725
SWITCH, REAR HYD
42
6927949
HYDRAULIC TUBE
43
6927957
SPACER
44
7178511
SOCKET, END
45
7178513
CAP, SOCKET
