Запчасти Bobcat T35100L REAR HYDRAULIC HOOK & TRAILER BRAKE (S/N A8HD11001 - 14999, A8GW11001 - 14999, A8GT11001 - 14999) ACCESSORIES & OPTIONS

1

000350-01U

WASHER

2

000350-08C

WASHER

3

000350-21R

WASHER

4

01605.5

Screw

5

008372-14Q

ELBOW

6

008372-21X

TEE

7

008372-34M

UNION

8

010370-90W

ELBOW PIECE

9

10947.0

Screw

10

014375-30H

UNION

11

7186826

COUPLER, QUICK FEMALE Was 95993.2 - A

12

022375-28V

UNION

13

1CM2060

SCREW Was 39584.8 - A

14

43824.2

Rivet

15

56029.2

Plug

16

65285.9

Elbow

17

65614.0

Union

18

68566.9

Screw

19

69485.1

T- union

20

78743.2

Drain plug

21

79170.7

Coupling

22

1CM650

SCREW Was 48829.6 - A

22

80643.0

Screw

23

7225260

WASHER Was 89516.9 - A

24

89519.3

Washer

25

96568.1

Union

26

96580.6

Union

27

96589.7

Wire harness

28

PLATE, SERIAL NO. NAP

29

98353.6

Plate

30

98360.1

Union

31

100345-06W

NUT

32

100345-20M

NUT

33

7228465

FITTING, HYD ELBOW Was 100370-06P - A

34

100372-06G

UNION

35

100375-38S

UNION

36

100375-56M

UNION

37

100338-23F

SCREW

38

6911079

HYDRAULIC BLOCK

39

6911845

SOLENOID 2-2

40

6912226

FLEXIBLE

41

6913021

Support

42

6913650

Hose

43

6913675

FLEXIBLE

44

6913675

FLEXIBLE

45

6913684

Hose

46

6915262

VALVE

47

6915305

SPACER

48

6916079

HOSE

49

6916961

HOSE

50

6917366

HOOK Was 82425.0 - A

51

6913684

Hose

51

6917394

HOSE

52

6917437

Tube

53

6919773

UNION

54

6922478

REAR HOOD Was 6919717 - A

55

6925927

HOSE Was 6910391 - A

56

6925927

HOSE Was 6910391 - A

57

96598.8

Switch (proportional)

57

6927721

SWITCH, HYD HOOK

58

7178511

SOCKET, END

59

65784.1

Blank Plug

59

7178513

CAP, SOCKET

60

01620.4

Screw

61

15323.9

Washer

62

7179623

SLEEVE Was 61358.8 - A

63

63860.1

Mirror

64

79300.0

Pipe

65

84648.5

Plate

66

100228-57K

COVER

67

7009791

CABLE PULL
