HYDRAULIC CIRCUITRY (Fan Pump)

Запчасти Bobcat TL470HF HYDRAULIC CIRCUITRY (Fan Pump) HYDRAULIC SYSTEM

Схема запчастей Bobcat TL470HF - HYDRAULIC CIRCUITRY (Fan Pump) HYDRAULIC SYSTEM
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

7225629

PUMP, FAN See Illustration FAN PUMP/ EM9969

2

7231389

TUBELINE, HYD

3

16KB0808

FITTING, HYD CONNECTOR

4

17KB0404

FTG HYD ELBOW 90

5

17KB0810

FITTING, HYD ELBOW

6

18KB1616

FITTING, HYD ELBOW

7

1CM1025

BOLT Was 29CM1025 - A

8

87F6

FITTING

9

18EM1019

WASHER

10

6GM1025

SCREW Was 29CM1025 - A
