Запчасти Bobcat 3400XL BODY, SEAT & BASE (Bucket Seat) (S/N AJNW11001 - 19999) MAIN FRAME

1

7018899

BOLT

2

SEAT, GUNMETAL ASSY See Illustration BODY, SEAT & BASE/ SEAT1234XL500 - NLA - Order 7023381 cover and 7023379 seat back - Was 7017431 - A

3

SEAT, GUNMETAL ASSY See Illustration BODY, SEAT & BASE/ SEAT1234XL500 - NLA - Order 7023380 seat bottom - W/Ref. 9, 10 & 12

4

7016406

INSULATOR, FOIL, SEAT Was 7016407 - D

5

7016804

BASE, CAB SEAT

6

7016413

GROMMET

7

7025298

SEATBELT, 3PT W/Ref. 10 & 16 - Was 7023117 - A

8

7016334

COVER, SEAT BACK, CENTER, BLK

9

7016091

BOLT

10

7016512

NUT

11

7016319

CONSOLE, SEAT, BLK

12

7016650

SCREW

13

7016805

BASE, CAB SEAT FRONT, BLK

14

7016531

PAD, REAR, SEAT BASE

15

7018902

RIVET

16

7020704

BOLT

17

7024106

WASHER, RUBBER
