Запчасти Case IH RS561A (2-016) - CLUTCH MOUNTING ASSEMBLY Driveline

1

700719452

UNION

rotary

1шт.

2

700719436

BOLT

3/8" x 1 1/2", hex. socket head shoulder screw, SPL

6шт.

3

700719451

CYLINDER ASSY.

hydraulic, includes: REF.15

1шт.

4

700719432

CLUTCH ASSEMBLY

1шт.

5

483-1386

SET SCREW,Hex Soc, 3/8"-16 x 3/8"

3/8"-16 x 3/8", cup point hex. socket set, NP

1шт.

6

61481

KEY

3/8" x 1 1/4"

1шт.

7

483-13812

SET SCREW,Hex Soc, 3/8"-16 x 3/4"

3/8"-16 x 3/4", cup point hex. socket set, NP

1шт.

8

52712

BUSHING

1 1/2" x 18, narrow rim machinery, GA

2шт.

9

700719447

BEARING, NEEDLE

1.500, Bore

2шт.

10

700132730

SPROCKET ASSY.

WA

1шт.

11

219-8

LUBE NIPPLE,1/4" - 28 NPTF

1шт.

12

413-616

BOLT,Hex, 3/8" - 16 x 1", Gr 5

4шт.

13

492-11038

LOCK WASHER,3/8"

4шт.

14

700132584

BUSHING

1шт.

15

700719686

SEAL KIT

KIT

1шт.
