Запчасти Case IH 610 (03-009) - BOOM SPRAY VALVE ASSEMBLY (09) - BOOMS

1

BN8195028

FLANGE

2" HB FLNGD IN

1шт.

2

BN8195296

FLANGE

2" MPT FLNGD IN

1шт.

3

NS

NOT SERVICED

2" Actuator Valve Assembly

1шт.

3a

BN2399401

ADAPTER

Male, 1/4" Tube

2шт.

Service Parts for Ref. 3

1шт.

3b

87268421

HYDRAULIC VALVE

Butterfly, Bray, With Actuator

1шт.

Service Parts for Ref. 3

1шт.

4

87310322

NUT

Hex, 5/8-11, GB, DOR

4шт.

Not Shown

1шт.

5

87310192

BOLT

5/8"-11 x 4", G5

4шт.
