Запчасти Case IH 700 (35.900.13) - CYLINDER, TOOLBAR (35) - HYDRAULIC SYSTEMS

1

9652

HYDRAULIC CYLINDER,Double Acting, 44.5mm Rod, 610mm Stroke

4" x 24" Monarch 3000 psi no pins 1 3/4" rod 1/2" fb ports inline

1шт.

70' Only

1шт.

Refer to 35.900.07

1шт.

1

9652R

REMAN-HYD CYLINDER

700 FLEX HOE DRILL, TOOLBAR, 70' Only, 4" x 24" Monarch 3000 psi no pins 1 3/4" rod 1/2" fb ports inline (7/08-)

1шт.

1

9652C

CORE-HYD CYLINDER

Return Number

1шт.

1

87505357

HYDRAULIC CYLINDER,Double Acting, 38.1mm Rod, 609.6mm Stroke

3 1/2" x 24" 3000 psi no pins

1шт.

60' Only

1шт.

Refer to 35.900.08

1шт.

2

87329788

90 ELBOW,90 Degree, 9/16"-18, 37 Degree x 3/4"-16, O-Ring

1шт.

3

128817

HYD CONNECTOR,3/4" - 16 ORB x 9/16" - 18 JIC

1шт.

4

3326

PIN

cylinder 1" x 2 7/8" ul hardened with snap rings

2шт.

5

87019495

SNAP RING,#98, Ext

4шт.
