(61.901.AF[03]) - METERING DRIVE SHAFT FOR 6 ROW CABLE DRIVE

Запчасти Case IH 1225 EARLY RISER (61.901.AF[03]) - METERING DRIVE SHAFT FOR 6 ROW CABLE DRIVE (61) - METERING SYSTEM

Схема запчастей Case IH 1225 EARLY RISER - (61.901.AF[03]) - METERING DRIVE SHAFT FOR 6 ROW CABLE DRIVE (61) - METERING SYSTEM
3
8
61.901.ab[03]
1
5
6
3
5
4
1
6
3
7
6
8
8
1
2
6
61.901.ab 03
4
7
2
8
3
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

102724A2

BALL BEARING,22.6mm ID

.875 Hex bore

3шт.

2

22224

COLLAR

Lock

2шт.

3

132421A1

BAR

Input 7/8"

1шт.

4

353037A1

SPROCKET

34 Tooth

1шт.

5

86624123

SET SCREW,Hex Skt, 1/2" - 13 x 1/2"

2шт.

6

84553071

FLANGE BOLT

3/8 X 3

16шт.

7

86521613

BOLT,Hex, 3/8" - 16 x 1", Gr 5

2шт.

8

86521606

FLANGE NUT,Hex, 3/8" - 16, Gr 5

18шт.
