(75.200.28) - PNEUMATIC DOWN PRESSURE - AIR PUMP ASSEMBLY, PTO DRIVELINE

Запчасти Case IH 1240 (75.200.28) - PNEUMATIC DOWN PRESSURE - AIR PUMP ASSEMBLY, PTO DRIVELINE (75) - SOIL PREPARATION

Схема запчастей Case IH 1240 - (75.200.28) - PNEUMATIC DOWN PRESSURE - AIR PUMP ASSEMBLY, PTO DRIVELINE (75) - SOIL PREPARATION
75.200.29
1
5
6
3
7
8
4
9
10
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

87758237

BRACKET

compressor mount base

1шт.

3

87734598

BRACKET

pneumatic pump protection with decals

1шт.

4

88206

BOLT,Hex, 3/8" - 16 x 1", Gr 5

6шт.

5

80680

LOCK WASHER,3/8 0.381 CST ZND

6шт.

6

9628503

NUT,3/8"-16, G5

6шт.

7

87670

BOLT,1/2" - 13 x 1-1/4", Full Thd, Gr 5

2шт.

8

86512371

SERRATED NUT,Flg, USR, 1/2"-13

2шт.

9

87720301

DECAL

pneumatic down pressure setting

1шт.

10

87697284

DECAL

safety

2шт.
