(75.110.25) - LIQUID FERTILIZER - TANK AND FRAME - 24 ROW, 400 GALLON TANK

Запчасти Case IH 1250 (75.110.25) - LIQUID FERTILIZER - TANK AND FRAME - 24 ROW, 400 GALLON TANK (75) - SOIL PREPARATION

Схема запчастей Case IH 1250 - (75.110.25) - LIQUID FERTILIZER - TANK AND FRAME - 24 ROW, 400 GALLON TANK (75) - SOIL PREPARATION
5
10
1
4
2
75.110.26
9
7
8
3
6
11
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

87641796

FRAME

liquid fertilizer tank

1шт.

2

87503060

U-BOLT

us 3/4"-10 x 8.1 wide x 17.75 deep

2шт.

3

87502955

U-BOLT

us 5/8" 4"w 3 1/2"d

4шт.

4

12034871

WASHER

5/8"

8шт.

5

280374

NUT,Hex, 5/8" - 11, Gr 5

8шт.

6

87607554

TANK

400 gallon

1шт.

7

280954

NUT,3/4"-10, G5

4шт.

8

87647049

PLATE

strap anchor

4шт.

9

87660683

STRAP

400 gallon fertilizer tank

2шт.

10

87657981

BOLT

3/8"-16 x 5", G5, Full thread

8шт.

11

231-1446

NUT,3/8" - 16, Gr 5

8шт.
