Запчасти Case IH 1260 (80.150.12[01]) - BULK FILL - 18 PORT INDUCTOR (80) - CROP STORAGE/UNLOADING

1

84299151

REINFORCEMENT

strap reinforcement

2шт.

2

86511683

HEX SOC SCREW,3/8" - 16 x 1 3/4"

4шт.

3

88436

BOLT,Hex, 3/8" - 16 x 2", Gr 5

14шт.

4

87016

WASHER,0.41" ID x 0.81" OD x 0.07" Thk

14шт.

5

88902

NUT,3/8"-16

18шт.

6

87676529

DISTRIBUTOR

inductor assembly, 18 port

1шт.

7

NSS

NOT SOLD SEPARAT

GRATE shut-off assembly

1шт.

See Figure 80.150.23

1шт.
