Запчасти Case IH 800 (09-10) - MARKERS, HYDRAULIC CYLINDER, 2 X 8 INCH SINGLE ACTING, UNITS A THRU Y (08) - HYDRAULICS

145622C91

CYLINDER ASSY.,Double Acting, 50.8mm Rod, 204.7mm Stroke

CYLINDER ASSY, hydraulic, service parts are

1шт.

1

145621C1

HYD TUBE

BODY ASSY, hyd cylinder

1шт.

2

WIPER, rod (NSS), order kit, 145682C1

1шт.

3

O-RING, 2 x 2-3/8 class 6 (NSS), order kit, 145682C1

1шт.

4

WASHER, back-up (NSS), order kit, 145682C1

1шт.

5

149611C1

PISTON ROD

ROD

1шт.

6

RING, rod retainer (NSS), order kit, 145682C1

1шт.

145682C1

SEALING RING

KIT, hyd cylinder service, consists of ref nos. 2, 3, 4 and 6

1шт.
