(8-188) - HYDRAUALIC LAYOUT, AFS PLANTER, 12/23 SRC

Запчасти Case IH 955 (8-188) - HYDRAUALIC LAYOUT, AFS PLANTER, 12/23 SRC (08) - HYDRAULICS

Схема запчастей Case IH 955 - (8-188) - HYDRAUALIC LAYOUT, AFS PLANTER, 12/23 SRC (08) - HYDRAULICS
59
48
6
58
73
61
5
20
11
56
70
6
62
39
5
60
57
54
51
2
16
42
67
6
48
48
52
38
50
27
7
63
28
5
13
36
6
11
11
41
74
53
53
20
72
47
26
13
37
49
50
62
18
45
59
47
62
38
27
56
45
40
48
46
1
53
18
7
49
48
51
31
28
9
5
66
54
68
74
65
69
37
28
15
1
5
48
6
10
4
73
46
71
30
9
40
8
17
39
9
52
6
6
71
19
7
72
19
71
3
7
44
12
61
71
42
63
52
7
7
12
56
28
48
26
30
52
45
36
9
33
2
50
60
14
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

45

306132C1

CABLE TIE,14.5" L

STRAP - tie, 14 inch long

12шт.

46

133467A1

PLATE

- hose mounting

4шт.

47

133501A1

PLATE

- hose mounting

2шт.

48

276-14812

SELF-TAP SCREW,Hex Wash Hd, 5/16" x 3/4"

SCREW - self-tapping, hex head, 5/16 NC x 3/4 inch

14шт.

49

218-673

FITTING,Blkhd, 9/16"-18, 37 Degree x 9/16"-18, 37 Degree

FIT STL BULKHD .375MJ .375MJ

6шт.

50

218-1255

BHD LOCK NUT,Blkhd, 3/4"-16

NUT, LOCK, Blkhd, 3/4"-16

6шт.

51

218-980

ELBOW,90 Degree, 9/16"-18, 37 Degree x 9/16"-18, 37 Degree Fem Sw

- 90 degree, 9/16-18 inch flare x swivel

6шт.

52

218-674

FITTING,Blkhd, 3/4"-16, 37 Degree x 3/4"-16, 37 Degree

ADAPTER - straight, 3/4-16 inch flare x bulkhead flare

8шт.

53

218-1254

LOCK NUT,Blkhd, 9/16"-18

NUT - hex, lock, bulkhead, 9/16 inch NF

8шт.

54

218-5173

ELBOW,45 Degree Elbow, 3/4" - 16 Male JIC x 3/4" - 16 Female JIC

- 45 degree, 3/4-16 inch flare x swivel

4шт.

56

218-5230

ELBOW,90 Degree, 3/4"-16, 37 Degree x 3/4"-16, 37 Degree Fem Sw

- 90 degree, 3/4-16 inch flare x swivel

8шт.

57

250961A2

HYDRAULIC HOSE,15.90 mm ID x 3556.00 mm, SAE 100R2 or SAE 100R16

15.90 mm ID x 3556.00 mm, SAE 100R2 or SAE 100R16

1шт.

58

250962A2

HYDRAULIC HOSE,15.90 mm ID x 3810.00 mm, SAE 100R2 or SAE 100R16

15.90 mm ID x 3810.00 mm, SAE 100R2 or SAE 100R16

1шт.

59

810604C1

HYDRAULIC HOSE

HOSE - 735 mm (29 inch) long

2шт.

60

1254527C2

HYDRAULIC HOSE

HOSE - 940 mm (37 inch) long

2шт.

61

1285380C2

HYDRAULIC HOSE

HOSE - 1270 mm (50 inch) long

1шт.

62

90685C1

HYDRAULIC HOSE,12.70 mm ID x 4825.00 mm, SAE 100R1

2шт.

63

91159C1

HYDRAULIC HOSE,12.70 mm ID x 4955.00 mm, SAE 100R1

HYDRALUIC HOSE, 12.70 mm ID x 4955.00 mm, SAE 100R1

2шт.

64

218-980

ELBOW,90 Degree, 9/16"-18, 37 Degree x 9/16"-18, 37 Degree Fem Sw

- 90 degree, 9/16-18 inch flare x swivel

2шт.

65

298624A1

VALVE

ASSEMBLY - load check, double acting, see page 8-143B

1шт.

66

91163C1

HYDRAULIC HOSE,9.65mm ID x 1193.8mm L, SAE 100R1

1шт.

67

413-436

BOLT,Hex, 1/4" - 20 x 2-1/4", Gr 5

2шт.

68

492-11025

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

2шт.

69

425-104

NUT,1/4"-20, Cl 5

- hex, 1/4 inch NC

2шт.

70

250720A1

LARGE PLATE

PLATE - hose mounting

1шт.

71

218-5232

ELBOW,90 Degree, 7/8"-14, 37 Degree x 7/8"-14, 37 Degree Fem Sw

- 90 degree, 7/8-14 inch flare x swivel

8шт.

72

218-675

FITTING,Blkhd, 7/8"-14, 37 Degree x 7/8"-14, 37 Degree

FIT STL BULKHD .625MJ .625MJ

4шт.

73

218-1251

BHD LOCK NUT,Blkhd, 7/8"-14

NUT, LOCK, Blkhd, 7/8"-14

4шт.

74

31-1228

HYDRAULIC HOSE

HOSE - 1118 mm (44 inch) long

4шт.

75

218-5107

90 ELBOW,90 Degree Elbow, 7/8" - 14 Male JIC x 7/8" - 14 Male ORB

- 90 degree, 7/8-14 inch flare x adj O-ring boss

2шт.
