(35.900.34) - HYDRAULICS - 60 10" OUTER WING TRIP LOWER CCT

Запчасти Case IH 800 (35.900.34) - HYDRAULICS - 60 10" OUTER WING TRIP LOWER CCT (35) - HYDRAULIC SYSTEMS

Схема запчастей Case IH 800 - (35.900.34) - HYDRAULICS - 60 10" OUTER WING TRIP LOWER CCT (35) - HYDRAULIC SYSTEMS
28
3
17
3
3
45
17
25
3
28
23
25
7
25
25
16
16
7
25
25
3
16
23
23
25
25
3
16
7
23
3
25
1
2
1
23
45
28
23
23
35.900.65
23
19
35.900.65
3
15
2
28
23
19
25
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

86513043

4 WAY CONNECTION,3/4"-16, 37 Degree

1шт.

2

86624135

REDUCER,37 Degree, 3/4"-16, Fem x 9/16"-18 Male

2шт.

3

76355

TEE,9/16" - 18 JIC x 9/16" - 18 JIC x 9/16" - 18 JIC

5шт.

7

86513042

4 WAY CONNECTION,9/16"-18, 37 Degree

1шт.

15

393704R92

HYDRAULIC HOSE

3/8" x 31" fl

1шт.

16

1284323C1

HYDRAULIC HOSE

3/8" x 15" (380 mm)

2шт.

17

84233753

HYDRAULIC HOSE

10 mm x 1150 mm fl

1шт.

19

1284301C1

HYDRAULIC HOSE

3/8" x 45" fl

1шт.

23

84233744

HYDRAULIC HOSE,6.35mm ID x 560mm L, SAE 100R17

6.3 mm x 560 mm fl

6шт.

25

84241095

HYDRAULIC HOSE

6.3 mm x 1230 mm fl

6шт.

28

1251872C2

HYDRAULIC HOSE

3/8" x 23" fl, 3/8" fjic x 3/8" fjic

2шт.

45

1023091

HYDRAULIC HOSE

1/2" x 162" fl

1шт.

Refer to 35.900.65

1шт.
