(35.900.40) - HYDRAULICS - 60 12" OUTER WING TRIP LOWER CCT

Запчасти Case IH 800 (35.900.40) - HYDRAULICS - 60 12" OUTER WING TRIP LOWER CCT (35) - HYDRAULIC SYSTEMS

Схема запчастей Case IH 800 - (35.900.40) - HYDRAULICS - 60 12" OUTER WING TRIP LOWER CCT (35) - HYDRAULIC SYSTEMS
45
38
27
23
38
27
3
38
27
35.900.65
35.900.65
7
29
2
38
38
7
27
2
27
3
3
23
3
23
19
38
1
23
27
34
23
45
27
23
19
29
23
3
27
3
34
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

86513043

4 WAY CONNECTION,3/4"-16, 37 Degree

1шт.

2

86624135

REDUCER,37 Degree, 3/4"-16, Fem x 9/16"-18 Male

2шт.

3

76355

TEE,9/16" - 18 JIC x 9/16" - 18 JIC x 9/16" - 18 JIC

2шт.

7

86513042

4 WAY CONNECTION,9/16"-18, 37 Degree

2шт.

19

1284301C1

HYDRAULIC HOSE

3/8" x 45" fl

1шт.

23

84233744

HYDRAULIC HOSE,6.35mm ID x 560mm L, SAE 100R17

6.3 mm x 560 mm fl

4шт.

27

84233746

HYDRAULIC HOSE

6.3 mm x 1380 mm fl

5шт.

29

87723329

HYDRAULIC HOSE

10 mm x 1095 mm fl

1шт.

34

84233748

HYDRAULIC HOSE

6.3 mm x 1075 mm fl

1шт.

38

1251872C2

HYDRAULIC HOSE

3/8" x 23" fl, 3/8" fjic x 3/8" fjic

3шт.

45

1023091

HYDRAULIC HOSE

1/2" x 162" fl

1шт.

Refer to 35.900.65

1шт.
