(35.900.41) - HYDRAULICS - 60 12" OUTER WING TRIP LIFT CCT

Запчасти Case IH 800 (35.900.41) - HYDRAULICS - 60 12" OUTER WING TRIP LIFT CCT (35) - HYDRAULIC SYSTEMS

Схема запчастей Case IH 800 - (35.900.41) - HYDRAULICS - 60 12" OUTER WING TRIP LIFT CCT (35) - HYDRAULIC SYSTEMS
14
14
7
19
32
14
19
28
14
3
3
45
45
32
14
36
28
32
36
3
28
3
1
3
2
28
2
32
14
32
7
29
3
32
32
14
29
32
35.900.65
35.900.65
28
28
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

86513043

4 WAY CONNECTION,3/4"-16, 37 Degree

1шт.

2

86624135

REDUCER,37 Degree, 3/4"-16, Fem x 9/16"-18 Male

2шт.

3

76355

TEE,9/16" - 18 JIC x 9/16" - 18 JIC x 9/16" - 18 JIC

2шт.

7

86513042

4 WAY CONNECTION,9/16"-18, 37 Degree

2шт.

14

84238339

HYDRAULIC HOSE

6.3 mm x 500 mm fl

4шт.

19

1284301C1

HYDRAULIC HOSE

3/8" x 45" fl

1шт.

28

1251872C2

HYDRAULIC HOSE

3/8" x 23" fl, 3/8" fjic x 3/8" fjic

3шт.

29

87723329

HYDRAULIC HOSE

10 mm x 1095 mm fl

1шт.

32

84233747

HYDRAULIC HOSE

6.3 mm x 1200 mm fl

5шт.

36

84233749

HYDRAULIC HOSE

6.3 mm x 895 mm fl

1шт.

45

1023091

HYDRAULIC HOSE

1/2" x 162" fl

1шт.

Refer to 35.900.65

1шт.
