(35.900.80) - FOLDAWAY FRAME CYLINDER

Запчасти Case IH 800 (35.900.80) - FOLDAWAY FRAME CYLINDER (35) - HYDRAULIC SYSTEMS

Схема запчастей Case IH 800 - (35.900.80) - FOLDAWAY FRAME CYLINDER (35) - HYDRAULIC SYSTEMS
4
3
1
3
2
35.900.72
2
4
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

86994102

HYDRAULIC CYLINDER,Double Acting, 34.92mm Rod, 203.2mm Stroke

3" x 8" 3000 psi da

1шт.

Refer to 35.900.72

1шт.

2

3326

PIN

cylinder 1" x 2 7/8" ul hardened with snap rings

2шт.

3

87019495

SNAP RING,#98, Ext

4шт.

4

87325444

WASHER,1.02" ID x 1.5" OD x 0.07" Thk

1 1/64" id 1 1/2" 14ga

4шт.
