(75.120.45) - BOOM PLUMBING GROUP, 5 SECTION, CENTER SECTION

Запчасти Case IH 3330 (75.120.45) - BOOM PLUMBING GROUP, 5 SECTION, CENTER SECTION (75) - SOIL PREPARATION

Схема запчастей Case IH 3330 - (75.120.45) - BOOM PLUMBING GROUP, 5 SECTION, CENTER SECTION (75) - SOIL PREPARATION
home
8
4
7
8
2
3
8
1
75.120.32
7
5
8
4
6
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

BN325195

VALVE

PLBG GRP, 5 SEC CTR

1шт.

2

BN53475

ELBOW,90 Degree Elbow, 1" Male NPT x 1" Hose Barb, Poly

1" NPT x 1" Hose Barb, Poly

1шт.

3

BN69394

HOSE

1" EPDM X 44.00"

1шт.

4

BN75990

HOSE CLAMP

#16, Stainless Steel

2шт.

5

BN50254

BOLT,3/8"-16 x 1", Stainless

2шт.

6

BN50759

LOCK NUT,3/8"-16, Nylon, Stainless

2шт.

7

342076A1

HOSE

1.5" x 147", EPDM

2шт.

8

BN310448

HOSE CLAMP

#28, Stainless Steel

4шт.
