(55.100.AI[04]) - FRAME MOUNTING CHANNEL

Запчасти Case IH PATRIOT 3340 (55.100.AI[04]) - FRAME MOUNTING CHANNEL (55) - ELECTRICAL SYSTEMS

Схема запчастей Case IH PATRIOT 3340 - (55.100.AI[04]) - FRAME MOUNTING CHANNEL (55) - ELECTRICAL SYSTEMS
4
10
8
2
3
11
39.100.ab 01
11
10
7
9
11
1
10
8
6
39.130.aa 01
5
3
6
39.130.aa 02
5
4
8
2
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

87739927

MOUNT

Harness

1шт.

2

86980400

BOLT,Hex, M10 x 25mm, Cl 8.8, Full Thd

3шт.

3

86980515

NUT,Hex, M10 x 1.5, Cl 8.8, DOR

3шт.

4

87529312

WASHER,11mm ID x 24mm OD x 3mm Thk

3шт.

5

BN570007

STRAP

14"

5шт.

6

515-2179

CLAMP,5/16", Insul, 1/4" Bolt

2шт.

7

87344030

NUT,Prevailing Torque, M5 x 0.8, CL 8, DOR

2шт.

8

87529301

WASHER,5.6mm ID x 10mm OD x 1mm Thk

5.6 x 10 x 1 mm CST DOR

2шт.

9

87021161

CLAMP,76.2mm, Coat, 8.7mm Bolt Hole, P Type

1шт.

10

87529314

WASHER,6.6mm ID x 12.5mm OD x 2mm Thk

6.6 x 12.5 x 2 mm, HDN, DOR

2шт.

11

86980513

NUT,Prev Torque, Hex, M6, 1mm Pitch, Cl 8, DOR

2шт.
