Запчасти Case IH 78 (AM-11[A]) - HYDRAULIC EQUIPMENT

381832R93

CYLINDER BLOCK

CYLINDER ASSY, 2 x 8 in. single acting hydraulic, refer to cyl, 1 for components

1шт.

386685R91

KIT

KIT, o-ring and seal service

1шт.

381833R93

CYLINDER ASSY.

CYLINDER ASSY, 2 x 8 in. double acting hydraulic, refer to cyl, 1 for components

2шт.

386685R91

KIT

KIT, o-ring and seal service

1шт.

371291R97

CYLINDER

ASSY, 2-1/2 x 8 in. double acting hydraulic, 7/8-14 straight thread outlets, refer to cyl, 1 for components

1шт.

363137R94

PACKAGE

KIT, o-ring and seal service

1шт.

371292R95

CYLINDER

ASSY, 3-1/2 x 8 in. double acting hydraulic, 7/8-14 straight thread outlets, refer to cyl, 1 for components

1шт.

363138R94

PACKAGE

KIT, o-ring and seal service

1шт.

403842R94

CYLINDER

ASSY, 3-1/2 x 8 in. double acting hydraulic, 7/8-14 straight thread outlets, for 3000 PSI hydraulic systems, refer to cyl, 1 for components

1шт.

527324R92

KIT

o-ring and seal service

1шт.

489743R1

HOSE W/90 DEG SWIVEL, 132 in. long, 2 used w/single acting cylinders, 4 used w/double acting cylinder, for Farmall 26, 56, 66 and 86 series tractors except 656 tractors w/hydraulic outlets under platform

1шт.

467803R91

HOSE

W/90 DEG SWIVEL, 98 in. long, 2 used w/single acting cylinders, 4 used w/double acting cylinders, for Farmall 656, 706, 806 and 1206 tractors w/hydraulic outlets in steering housing

1шт.

461166R91

HOSE ASSY.

HOSE ASSY, hydraulic 100 in. long, 2 used w/single acting cylinders, 4 used w/double acting cylinder, for Farmall 656 tractor with hydraulic outlets under platform

1шт.

462960R91

HOSE W/90 DEG SWIVEL 167 IN. LONG, 2 used w/single acting cylinders, 4 used w/double acting cylinders, for Farmall 66 and 86 series tractors w/hydraulic outlets in the rear

1шт.

395149R1

QUICK MALE COUPLING

COUPLING ASSY, self-sealing male, 2 used w/single acting cylinders, 4 used w/double acting cylinders

1шт.

371357R91

ELBOW

7/8-14 90 deg adjustable, 2 used w/single acting cylinders, 4 used w/double acting cylinders

1шт.

364885R1

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

3/4 x 15/16 x 3/32, 6 used w/single acting cylinders, 12 used w/double acting cylinders

1шт.

471301R2

ANGLE

MOUNTING, hose, tractors w/protective frame cab

2шт.

515030R1

CLAMP

hyd hose, tractors w/protective frame cab

1шт.

18685R1

CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1 1/2", Gr 2

BOLT, 3/8 x 1-1/2 znd crg

2шт.

126032

WING NUT,3/8"-16

NUT, 3/8-16 znd wing

2шт.

467750R1

WASHER

25/32 x 1-1/2 x 11 ga C-Z

2шт.

21610R1

BOLT,Hex, 3/4" - 10 x 2 1/2", Gr 8

SCREW, 3/4-10 x 2-1/2 znd hex-hd cap

2шт.

306132C1

CABLE TIE,14.5" L

STRAP, plastic tie 14 in

4шт.
