(A-27) - HYDRAULIC CYLINDER 4 X 8 IN., UNITS A, B AND C, MACHINES BUILT 1978 AND SINCE

Запчасти Case IH 315 (A-27) - HYDRAULIC CYLINDER 4 X 8 IN., UNITS A, B AND C, MACHINES BUILT 1978 AND SINCE

Схема запчастей Case IH 315 - (A-27) - HYDRAULIC CYLINDER 4 X 8 IN., UNITS A, B AND C, MACHINES BUILT 1978 AND SINCE
9
6
19
1
2
8
16
7
3
10
15
13
11
17
5
4
13
14
18
14
12
15
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

75766C91

CYLINDER ASSY HYDRAULIC, for service replacement order 548001R92

1шт.

1

75767C1

ROD

ASSY, tie

4шт.

2

75768C1

BASE

YOKE

1шт.

3

75756C1

PIN

1шт.

4

75757C1

PLUG

1шт.

5

75769C1

SLEEVE

1шт.

6

75770C1

HEAD

1шт.

7

75771C1

ROD

1шт.

121358

YOKE

5/8-NF type 5

1шт.

8

75772C1

PISTON

1шт.

9

75773C1

NUT

1шт.

10

75763C1

CLEVIS

1шт.

11

75764C1

PIN

1шт.

12

61-33828

HEX SOC SCREW,3/8"-16 x 1 3/4"

SCREW, 3/8 x 1-3/4 pl h/shd cap

1шт.

120377

NUT,3/8" - 16, Gr 5

1шт.

13

180523R1

PIN

2шт.

14

O-RING, note 1

3шт.

15

WASHER, back-up, see note 1

2шт.

16

O-RING, see note 1

1шт.

17

O-RING, see note 1

1шт.

18

WASHER, back-up, see note 1

1шт.

19

WIPER, see note 1

1шт.

812719C1

SEAL KIT

KIT, repair, consists of reference nos. 14 thru 19

1шт.
