(C-18[A]) - HYDRAULIC HOSE SUPPORT

Запчасти Case IH 60 (C-18[A]) - HYDRAULIC HOSE SUPPORT

Схема запчастей Case IH 60 - (C-18[A]) - HYDRAULIC HOSE SUPPORT
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

518843R1

SUPPORT

hose

1шт.

2

515030R1

CLAMP

hose

1шт.

15054R1

CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1 3/4", Gr 2

BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 3/4", G2

1шт.

129-410

WING NUT,3/8"-16

NUT, 3/8 wing type A

1шт.

Q1505

WASHER

13/32 x 1 x 16 ga

1шт.

3

363082R1

SPACER,3/8" Pipe x .656"

hose support

1шт.

4

(Not used this application)

1шт.

5

(Not used this application)

1шт.

6

(Not used this application)

1шт.
