1
397171A1
TUBE
6-Bolt Tandem Axle Inc. 2, 3
2шт.
Prior to 2007 Models
1шт.
1
87561153
CASTING
6-Bolt Tandem Axle
2шт.
Used On 2007 And After Models
1шт.
2
219-86
LUBE NIPPLE,1/8" NPTF
4шт.
3
17498D
TAPERED BEARING," ID x 76.2125 mm OD x 23.9135 mm
3.000 OD
4шт.
4
21871501
BEARING CONE,38.1mm ID x 25.65mm W
1.50 ID
4шт.
5
21932510
SEAL
2.29 ID
4шт.
6
06400573
SPACER
Bearing
4шт.
7
87401183
PIN,38.07mm OD x 325mm L
1-1/2, Tandem
2шт.
8
14032409
NUT
1-1/2, Special Jam
2шт.
9
425-146
JAM NUT,3/8" - 16, Gr 5
2шт.
10
16806045
SET SCREW,Sq Hd, 3/8" - 16 UNC x 1"
3/8 x 1, Set, Square Head
2шт.
11
413-1240
BOLT,Hex, 3/4" - 10 x 2-1/2", Gr 5
2шт.
12
280375
NUT,3/4"-10, GC
2шт.
13
86990480
SPINDLE
6 Bolt
4шт.
Prior to 2007 Models
1шт.
13
87517011
STUB AXLE/STEERING S
6 Bolt
4шт.
Used On 2007 And After Models
1шт.
14
594703R1
SLEEVE
Wear
4шт.
15
594702R91
SEAL
Type X15
4шт.
16
663557R91
BEARING ASSY,1.625" ID x 2.892" OD x 0.77"
1.625 ID
4шт.
17
87426111
HUB
With Cups, Inc. 18, 19
4шт.
18
663558R1
BEARING CUP
2.892 OD
4шт.
19
651817R1
BEARING CUP
2.33 OD
4шт.
19
651817R1GV
BEARING CUP
Value, Bearing Cup
4шт.
20
219-87
LUBE NIPPLE,1/4" - 28 NPTF
4шт.
21
651818R91
ROLLER BEARING,31.77 mm ID x 16.08 mm
1.25 ID
4шт.
22
469873R1
WASHER,23.01mm ID x 44.45mm OD x 3.05mm Thk
23/32 ID
4шт.
23
70120D
SLOTTED NUT,7/8"-14
4шт.
24
432-832
COTTER PIN,1/8" x 2"
4шт.
25
224066C1
HUB CAP
4шт.
26
277538A1
BOLT,1/2" - 20 x 1.42"
Wheel
24шт.
27
NSS
NOT SOLD SEPARAT
12.5L x 15 (10 Ply) I-1 Tubeless
4шт.
28
10110254
WHEEL ASSY.
15 x 10 lb SAE, Silver
4шт.
29
413-1072
BOLT,Hex, 5/8" - 11 x 4-1/2", Gr 5
4шт.
30
85700693
NUT,5/8" - 11, Gr C
4шт.
