(9B-37) - SHAKER SHAFT AND AUGER DRIVE (CONTD)

Запчасти Case IH 1680 (9B-37) - SHAKER SHAFT AND AUGER DRIVE (CONTD) (14) - ROTOR, CONCANVES & SIEVE

Схема запчастей Case IH 1680 - (9B-37) - SHAKER SHAFT AND AUGER DRIVE (CONTD) (14) - ROTOR, CONCANVES & SIEVE
49
48
37
55
54
52
50
39
38
53
36
47
48
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

36

REF

INSTRUCTION

PULLEY - shaker shaft driven, right drive (See Figure 9A-4), continued

1шт.

37

1303136C1

HUB

- shaker shaft drive slip clutch

1шт.

38

19302K

SPRING

- shaker shaft drive slip clutch

2шт.

39

167521H1

SPRING WASHER

- slip clutch retainer

1шт.

47

87414

LUBE NIPPLE,1/4" - 28

FITTING - grease, straight taper drive, 1/4-28 inch

1шт.

48

1302221C1

PLATE

- shaker shaft

2шт.

49

180955C1

FLANGED BEARING,0.375"

FLANGE - center shaker shaft bearing

2шт.

50

182544C1

SHIELD

- shaker shaft spring

1шт.

52

566516R91

PULLEY ASSY.

PULLEY - drive, spreader straw

1шт.

53

113-103

BOLT,Hex, 5/16" - 18 x 1", Gr 5

5шт.

54

9635082

NUT,5/16" - 18, Gr 5

5шт.

55

192-20

LOCK WASHER,Helical Spring, 0.318" ID, CST, ZND

WASHER, LOCK, 5/16"

5шт.
