Запчасти Case IH 2188 (9H-12) - RIGHT HAND DOOR AND SHIELD (12) - CHASSIS

1

193812C6

SHEET

SUPPORT - tail lamp, right-hand

1шт.

2

477-73112

SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 3/4"

- serrated slotted truss head, 5/16 NC x 3/4"

5шт.

3

231-5145

SERRATED NUT,Flg, USR, 5/16"-18

NUT - hex serrated flange, 5/16 inch NC

3шт.

4

488837C1

SPRING NUT

- speed, 5/16 inch

3шт.

5

194625C7

PANEL

SHIELD - rear trim, right-hand

1шт.

6

477-73108

SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 1/2"

BOLT - serrated slotted truss head, 5/16 NC x 1/2 inch

7шт.

6

190553A1

SCREW,Sl Truss Hd, 5/16" - 18 x 3/4"

- slotted truss head, painted head, 5/16 NC x 3/4 inch

5шт.

7

231-5145

SERRATED NUT,Flg, USR, 5/16"-18

NUT - hex serrated flange, 5/16 inch NC

12шт.

8

1319563C1

SUPPORT

- handle

1шт.

9

256873

BOLT,Hex Serr, 5/16" - 18 x 1/2", 5SPL, Full Thd

2шт.

10

231-5145

SERRATED NUT,Flg, USR, 5/16"-18

NUT - hex serrated flange, 5/16 inch NC

2шт.

11

139775A3

HOOD

DOOR - right-hand, forward

1шт.

12

182219A1

SUPPORT

BRACKET - latch support, right-hand lower

1шт.

13

256873

BOLT,Hex Serr, 5/16" - 18 x 1/2", 5SPL, Full Thd

3шт.

14

231-5145

SERRATED NUT,Flg, USR, 5/16"-18

NUT - hex serrated flange, 5/16 inch NC

3шт.

15

182195A1

ANGLE BAR

ANGLE - latch support

1шт.

16

409-7512

BOLT,Hex Flg, 5/16" - 18 x 3/4", Spcl

- hex serrated flange, 5/16 NC x 3/4 inch

2шт.

17

409-7516

BOLT,Hex Flg, 5/16" - 18 x 1", Spcl

9шт.

18

231-5145

SERRATED NUT,Flg, USR, 5/16"-18

NUT - hex serrated flange, 5/16 inch NC

11шт.

19

182262A2

SUPPORT

BRACKET - gas spring lower mounting

1шт.

20

256873

BOLT,Hex Serr, 5/16" - 18 x 1/2", 5SPL, Full Thd

4шт.

21

231-5145

SERRATED NUT,Flg, USR, 5/16"-18

NUT - hex serrated flange, 5/16 inch NC

4шт.

22

141224A1

LATCH

- door

1шт.

23

413-416

BOLT,Hex, 1/4" - 20 x 1", Gr 5

- hex, 1/4 NC x 1 inch

2шт.

24

182204A1

LEVER

- latch

1шт.

25

176203A2

PROTECTOR

CAP - lever end

1шт.

26

413-528

BOLT,Hex, 5/16" - 18 x 1-3/4", Gr 5

1шт.

27

425-145

JAM NUT,Jam, 5/16"-18, G5

1шт.

28

231-5145

SERRATED NUT,Flg, USR, 5/16"-18

NUT - hex serrated flange, 5/16 inch NC

1шт.

29

140311A3

GAS STRUT

CYLINDER - hydro-lift door

1шт.

This has a clip at each end and these are not serviced separately.

1шт.

STUD for attaching cylinder is Ref. 36 and NUT is Ref. 34.

1шт.

30

143442A2

SUPPORT

BRACKET - door stop, front

1шт.

31

187885C1

SEALING STRIP

- 29-1/2 inch (747 mm) long, cut from 87281C1 bulk seal below

1шт.

Part of P/N 87281C1 Seal

1шт.

32

139771A2

SUPPORT

ANGLE - cylinder mounting, upper right-hand

1шт.

33

477-73112

SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 3/4"

- serrated slotted truss head, 5/16 NC x 3/4"

6шт.

34

231-5145

SERRATED NUT,Flg, USR, 5/16"-18

NUT - hex serrated flange, 5/16 inch NC

6шт.

35

181333A1

ANGLE BAR

BRACKET - hinge support

1шт.

36

1340345C1

BALL STUD

STUD - ball

2шт.

37

231-5145

SERRATED NUT,Flg, USR, 5/16"-18

NUT - hex serrated flange, 5/16 inch NC

2шт.

38

182824A1

LEVER

- latch, Australia only

1шт.

39

184373A1

COVER

- latch arm, Australia only

1шт.

87281C1

RUBBER STRIP,38mm W x 749mm L x 19mm Thk

- bulk, 600 inch (15240 mm) long, Includes: Ref. 31

1шт.

282145A1

SPECIAL BOLT,1/2" - 13 x 3/4", Grade 8

LATCH

1шт.
