1
239801A2
HOUSING
Includes Decal, See Figure(s) 09H-20, Ref. 2; 09H-21, Ref. 9
1шт.
With 60 Inch Feeder
1шт.
1
239800A2
HOUSING
Includes Decal, See Figure(s) 09H-20, Ref. 2; 09H-21, Ref. 9
1шт.
With 54-1/2 Inch Feeder
1шт.
2
1994217C2
SHEET
Not Perforated
1шт.
With 60 Inch Feeder
1шт.
2
118845A1
BOTTOM
Perforated
1шт.
With 60 Inch Feeder
1шт.
2
1324578C2
PLATE
1шт.
With 54-1/2 Inch Feeder
1шт.
2
1313970C1
PANEL
Perforated
1шт.
With 54-1/2 Inch Feeder
1шт.
3
415-820
CARRIAGE BOLT,Sht Sq Nk, 1/2" - 13 x 1 1/4", Gr 8
1/2 x 1-1/4; 8
4шт.
5
433-1028
CARRIAGE BOLT,Sq Nk, 5/8" - 11 x 1 3/4", Gr 5
5/8 x 1-3/4
2шт.
6
433-1036
CARRIAGE BOLT,Sq Nk, 5/8" - 11 x 2 1/4", Gr 5
5/8 x 2-1/4
6шт.
7
498-81008
SQ HOLE WASHER,41/64" x 1 1/4" x .060", Sq Hole
21/32 x 1-1/4 x 1/16
6шт.
8
231-14410
NUT,5/8"-11, GB
6шт.
9
496-21066
WASHER,16.6mm ID x 33.5mm OD x 3.8mm Thk
6шт.
10
186852C1
FLANGE NUT,Hex, 1/2"-13, Lock
1/2, 8
4шт.
11
329-286
FLANGE NUT,Flg, 3/8"-16, G8
8-10шт.
12
434-616
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
2шт.
13
492-11038
LOCK WASHER,3/8"
2шт.
14
425-106
NUT,3/8"-16, Cl 5
2шт.
15
434-612
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 3/4", Gr 5
3/8 x 3/4
4шт.
16
231-5146
FLANGE NUT,3/8"-16
4шт.
17
477-73112
SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 3/4"
2шт.
18
231-5145
SERRATED NUT,Flg, USR, 5/16"-18
2шт.
19
477-73812
SERRATED SCREW,Truss HD, 3/8" - 16 x 3/4"
3/8 x 3/4
3шт.
20
231-5146
FLANGE NUT,3/8"-16
3шт.
21
241769A2
ADAPTER
1шт.
22
1338021C1
PIN,7.94mm OD
2шт.
23
231-1445
NUT,5/16"-18, GB
2шт.
24
495-11034
WASHER,5/16", SAE
(11/32 x 11/16 x 1/16")
4шт.
25
367833R1
SPRING
2шт.
26
177138C1
ROD
2шт.
27
179024C1
HINGE
2шт.
28
38-1816
LOCK PIN,1/8" x 1", Slotted
1/8" x 1", Slotted
2шт.
29
495-81175
WASHER,21/32" x 1" x .120"
21/32 x 1 x 7/64
4шт.
30
38-11616
LOCK PIN,1/4" x 1", Slotted
2шт.
31
177141C1
PIN,15.88mm OD x 41mm L
2шт.
32
1321735C2
BOLT,1/2" - 13 x 310mm, Gr 8
2шт.
33
329-108
NUT,1/2"-13, G8
4шт.
34
439-5836
HEADED PIN,12.7mm OD x 57.15mm L
1/2 x 2-1/4
2шт.
35
495-11053
WASHER,1/2", SAE
(17/32" x 1-1/16" x 3/32")
2шт.
36
432-1216
COTTER PIN,3/16" x 1"
2шт.
37
231-5145
SERRATED NUT,Flg, USR, 5/16"-18
16шт.
38
1327737C2
PLATE
2шт.
39
95-81018
WASHER,0.66" ID x 2.5" OD x 0.12" Thk
21/32 x 2-1/2 x 1/8
2шт.
40
184853C1
DEFLECTOR
Left Hand
1шт.
41
184854C1
DEFLECTOR
Right Hand
1шт.
42
477-73112
SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 3/4"
16шт.
43
1319474C1
BAND
1шт.
44
1319479C1
COVER
1шт.
45
409-7516
BOLT,Hex Flg, 5/16" - 18 x 1", Spcl
12шт.
46
495-21038
WASHER,5/16"
(flat, 3/8 x 7/8 x 3/32")
5шт.
46
495-81001
WASHER,5/16"
3/8 x 1-1/8 x 1/16
7шт.
47
232-4115
LOCK NUT,5/16"-18, GC
5шт.
47
231-5345
FLANGE NUT,Flg, 5/16"-18
5/16
7шт.
48
1321640C1
GROMMET
2шт.
49
1327752C1
FOAM INSULATION
Left Hand
1шт.
50
1327753C1
FOAM INSULATION
Right Hand
1шт.
51
109253A1
LARGE PLATE
PLATE, LARGE Cut From 1330108CX
1шт.
52
140767A2
HINGE
2шт.
53
140768A4
STEP
1шт.
57
126046A1
GASKET,287.02mm L
292 mm (11-1/2 in.), Cut From 1330108CX
2шт.
58
495-81030
WASHER,21/32" x 2" x .179"
21/32 x 2 x 11/64
6шт.
59
477-73808
SERRATED SCREW,Sl Truss Hd, 3/8" - 16 x 1/2"
3/8 x 1/2
4шт.
60
249827A1
COVER
4шт.
61
425-106
NUT,3/8"-16, Cl 5
4шт.
4
477-73816
SERRATED SCREW,Sl Truss Hd, 3/8" x 1"
8-10шт.
62
86616314
PACKAGE
Feeder House Step Extension
1шт.
