(35.204.14[02]) - HYDRAULICS- HEADER COUPLER BREAKDOWN

Запчасти Case IH 7130 (35.204.14[02]) - HYDRAULICS- HEADER COUPLER BREAKDOWN (35) - HYDRAULIC SYSTEMS

Схема запчастей Case IH 7130 - (35.204.14[02]) - HYDRAULICS- HEADER COUPLER BREAKDOWN (35) - HYDRAULIC SYSTEMS
1
4
4
3
4
home
5
4
4
5
2
6
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

84435502

HYD CONNECTOR

Includes Seal 86623898, Ref 5

1шт.

86623898

SEAL,1mm OD x 3.2mm Thk

1шт.

2

84435503

HYD CONNECTOR

Incl Seal 86623898, Ref 5

1шт.

86623898

SEAL,1mm OD x 3.2mm Thk

1шт.

3

87691267

COUPLING

Includes Quant 1 of Seal 86623899

3шт.

86623899

SEAL KIT,13mm OD x 2.5mm Thk

3шт.

4

86623900

REPAIR KIT

Contains Thump Screw, Pin, Oring, Nut, and Bushing

1шт.

5

86623898

SEAL,1mm OD x 3.2mm Thk

2шт.

6

86623899

SEAL KIT,13mm OD x 2.5mm Thk

3шт.
