(44.100.06) - WHEEL, DUAL FRONT, 710/70R42, EU ONLY

Запчасти Case IH 7230 (44.100.06) - WHEEL, DUAL FRONT, 710/70R42, EU ONLY (44) - WHEELS

Схема запчастей Case IH 7230 - (44.100.06) - WHEEL, DUAL FRONT, 710/70R42, EU ONLY (44) - WHEELS
1
2
3
4
6
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

NS

NOT SERVICED

Procure Locally

1шт.

2

84182774

RIM

WHEEL ASSY, 42XF-DW23B SILVER

1шт.

3

395448

VALVE STEM

1шт.

4

87106340

PLUG

Not Used

1шт.

5

NS

NOT SERVICED

No Tube Used In This Application

1шт.

6

87570139

DECAL

Bolt Torquing Sequence

1шт.
