(90.118.26) - MIRROR, REAR VIEW, STANDARD - 7010/8010

Запчасти Case IH 8010 (90.118.26) - MIRROR, REAR VIEW, STANDARD - 7010/8010 (90) - PLATFORM, CAB, BODYWORK AND DECALS

Схема запчастей Case IH 8010 - (90.118.26) - MIRROR, REAR VIEW, STANDARD - 7010/8010 (90) - PLATFORM, CAB, BODYWORK AND DECALS
8
10
11
6
12
5
8
5
1
3
10
2
12
90.118.27
6
4
13
9
13
7
11
7
9
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

84073711

ARM

CARRIAGE Swing, LH

1шт.

2

84073713

ARM

CARRIAGE Swing, RH

1шт.

3

87107208

MIRROR

Rear View, LH, Includes: Refs 5 & 6

1шт.

4

87107209

MIRROR

Rear View, RH, Includes: Refs 5 & 6

1шт.

5

NSS

NOT SOLD SEPARAT

GLASS Mirror

2шт.

6

84434473

COVER

2шт.

7

84059856

WIRE CONNECTOR

WEDGE Mounting

2шт.

8

84320374

LAMP,Halogen, 12V, 50W, Clear

ASSY, Includes: Refs 9 Thru 13

2шт.

9

9847312

BULB

12V, 50W, Halogen

2шт.

10

9991588

NUT,M8 x 1.25, Cl 8

1шт.

11

412712

BELLEVILLE WASHER,M8 x 18 x 1 Thk

1шт.

12

84431556

BOLT,Hex, M8 x 50mm, Cl 8.8

1шт.

13

NSS

NOT SOLD SEPARAT

CLAMP

2шт.
