1
87696391
GEARBOX ASSY
Rotor, Three Speed
1шт.
7120 & 8120 Only
1шт.
1
87696391R
REMAN-GEARBOX
Reman Gearbox, 7120 & 8120
1шт.
1
87696391C
CORE-GEARBOX
Return Number
1шт.
1
87687514
GEARBOX ASSY
Rotor, Three Speed
1шт.
9120 Only
1шт.
1
87687513R
REMAN-ROTOR ASSY
Remanufactured Rotor Drive, 9120 Only
1шт.
1
87687513C
CORE-ROTOR
ASSY Return Number
1шт.
2
258854A2
U-JOINT SPIDER
2шт.
7120 & 8120 Only
1шт.
2
259076A2
U-JOINT SPIDER
2шт.
9120 Only
1шт.
3
87016255
SNAP RING,#250, 2.356, Ext
1шт.
4
86980985
GEAR,39T Internal / 12T External
Center Rotor, Inner
1шт.
5
87000091
WASHER,13mm ID x 77mm OD x 12mm Thk
1шт.
6
87018388
BOLT,Hvy Hex, M12 x 45mm, Cl 10.9
1шт.
7
357545
HANDLE GRIP
1шт.
8
87485712
DRAINCOCK/TAP SUPPLY
1шт.
9
86639054
45 ELBOW,45 Degree, 1-7/16"-12 ORFS x M33 x 2.0 ORB
45°
1шт.
10
87553424
TUBE,1" OD
Rotor Gearbox Dipstick
1шт.
11
84153776
DIPSTICK
1шт.
12
87106209
BRACKET
1шт.
8120 & 9120 Only
1шт.
13
600427
CLAMP,25.4mm, Coat, 8.7mm Bolt Hole, P Type
1шт.
14
120104
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
1шт.
15
322358
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
1шт.
16
87105603
SENSOR
Rotor Speed Sensor
1шт.
17
87017895
BOLT,M16 x 2.0 x 70.18mm, Cl 10.9
6шт.
18
86625266
WASHER,17.5mm ID x 30mm OD x 4mm Thk
6шт.
19
87106105
SPACER
6шт.
20
86981464
FLANGE NUT,M16 x 2.0, Cl 10
6шт.
21
87109129
DRIVE SHAFT
Includes Ref 2 & 32, As Indicated
1шт.
7120 & 8120 Only
1шт.
21
87655130
SHAFT
Includes Ref 2 & 32, As Indicated
1шт.
9120 Only
1шт.
22
87017891
12 PT SCREW,M10 x 1.5 x 55mm, Cl 12.9
8шт.
23
86998008
CABLE,2900mm L
1шт.
24
9827902
CLAMP,25.4mm, Coat, 10.3mm Bolt Hole, P Type
2шт.
25
844-8025
BOLT,Hvy Hex, M8 x 25mm, Cl 8.8
3шт.
26
9804277
FLANGE NUT,Hex, M8 x 1.25, Cl 8
3шт.
27
412126
NUT,M12 x 1.75
1шт.
28
87106667
INDICATOR
Gear
1шт.
29
87107830
BRACKET
Shift Cable
1шт.
30
87107827
LEVER
Shift
1шт.
31
9706693
BOLT,M12 x 60mm, Cl 8.8
1шт.
32
87015535
BOLT,Hex, M10 x 45mm, Cl 10.9
8шт.
