1
86900862
WIRE HARNESS
Std Shoe
1шт.
8120 & 9120 Only
1шт.
1
86900861
WIRE HARNESS
Narrow Shoe
1шт.
7120 Only
1шт.
2
84131598
DETECTOR
Incl Ref 23 & 24
1шт.
8120 & 9120 Only
1шт.
2
84131597
DETECTOR
Incl Ref 23 & 24
1шт.
7120 Only
1шт.
3
86997800
BRACKET
1шт.
4
87342073
SENSOR
Shaker Speed
1шт.
5
86590413
BASE,15.87mm W x 22.22mm OAL x 9.9mm Thk
Base, Tie Wrap
3шт.
6
86566989
CABLE TIE,208mm L
CABLE STRAP
7шт.
7
445394
RIVET,Pop, 3/16" x 1/2" OAL
3шт.
8
619284
CLAMP,23.8mm, Coat, 10.3mm Bolt Hole, P Type
1шт.
9
120100
BOLT,M6 x 20mm, Cl 8.8
5шт.
10
412649
BELLEVILLE WASHER,M6 Bolt Size x 18mm OD x 1.4mm Thk
4шт.
11
9706755
NUT,M6, Cl 8
1шт.
12
353308
NUT,M6 x 1.0, Cl 8
4шт.
13
322357
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
5шт.
14
89837692
CLAMP
4шт.
15
86010402
CLAMP,12.7mm, Coat, 10.3mm Bolt Hole, P Type
4шт.
After 4/2009, 7020 uses quantity 1 and 8120, 9120 uses quantity of 3
1шт.
16
322358
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
4шт.
17
9706690
NUT,M8 x 1.25, Cl 8
4шт.
18
86619060
CARRIAGE BOLT,M8 x 1.25 x 16mm, Cl 8.8
4шт.
19
87630204
SENSOR
Tailings Volume, Serial Range: -Y9G207395
1шт.
19
84212481
SENSOR
Tailings Volume, Start Year: 01-APR-09, Start Serial: Y9G207395
1шт.
20
43128
BOLT,M8 x 1.25 x 30mm, Cl 8.8
2шт.
21
140016
WASHER,M8 x 16mm OD x 1.6mm Thk
4шт.
22
832-46408
NUT,M8 x 1.25, Cl 8
2шт.
23
NSS
NOT SOLD SEPARAT
Sensor, Grain Loss
1шт.
24
84131033
DAMPER,25mm OD x 62mm L
4шт.
25
87494198
ADJUSTING PLATE
, Start Year: 01-APR-09, Start Serial: Y9G207395
1шт.
26
86594406
CLAMP,15.9mm, Coat, 10.3mm Bolt Hole, P Type
, Start Year: 01-APR-09
1шт.
