1
87317063
V-BELT,3651mm Nominal Length x 22.33mm W
Drive
1шт.
2
86996714
PULLEY,346.5mm Idler Dia x 382.2mm OD
Shaker Flywheel
1шт.
3
87545449
SPACER
Shaker Shaft
1шт.
4
86996914
KEY
M10 x 8 x 75
2шт.
5
300389
BOLT,M12 x 1.75 x 35mm, Cl 8.8
1шт.
6
140046
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
2шт.
7
87023036
WASHER,0.53" ID x 2" OD x 0.25" Thk
1шт.
8
87313372
PULLEY,203.5mm OD
205 mm OD, 1 HC, Incl Ref 22 & 23
1шт.
9
130357
WASHER,35.3mm ID x 60.3mm OD x 1.52 Thk
3шт.
10
9832773
SPACER,36mm ID x 55mm OD x 7mm L
1шт.
11
87499861
IDLER,185.67mm OD
Idler
1шт.
12
120047
CARRIAGE BOLT,M16 x 70mm, Cl 8.8
1шт.
13
140020
WASHER,17.5mm ID x 30mm OD x 3mm Thk
5шт.
14
86512555
NUT,M16 x 2, Cl 10
2шт.
15
86588003
IDLER,51.6mm W x 228.6mm OD
1шт.
16
84425098
ARM
Shaker Pivot Idler - Incl Ref 24
1шт.
17
300663
CARRIAGE BOLT,M16 x 2.0 x 120mm, Cl 8.8
1шт.
18
86999741
SPACER,16.5mm ID x 30mm OD x 35mm L
Shaker Pivot Idler
1шт.
19
300388
BOLT,Hex, M12 x 1.75 x 25mm, Cl 8.8
1шт.
20
29684
WASHER,13.5mm ID x 50.8mm OD x 5.52mm Thk
17/32" ID x 2" OD x 3/16" Thk
1шт.
21
86980549
SPRING
Shaker Pivot Idler
1шт.
22
393599
SET SCREW,M10 x 25mm, Cl 12.9
3шт.
23
100016
NUT,M10 x 1.5, Cl 8
3шт.
24
87629473
BUSHING,34.45mm ID x 43.42mm OD x 56mm L
1шт.
25
NS
NOT SERVICED
Kit No Longer Serviced
1шт.
