Запчасти Case IH 9010 (10.406.08[02]) - FAN SHROUD - PRIOR TO PIN HAJ202001 - 8010 (10) - ENGINE

1

87109228

PANEL

Blockoff

1шт.

For Use With Plastic Rotary Air Screen

1шт.

1

87354452

PANEL

Blockoff

1шт.

For Use With Metal Rotary Air Screen

1шт.

Also Included In Kit 87721403

1шт.

2

87284370

SHIELD

L.H.

1шт.

For Use With Plastic Rotary Air Screen

1шт.

2

87355718

HOUSING ASSY.

L.H.

1шт.

For Use With Metal Rotary Air Screen

1шт.

Also Included In Kit 87721403

1шт.

3

87284372

SHIELD

R.H.

1шт.

For Use With Plastic Rotary Air Screen

1шт.

3

87355721

HOUSING ASSY.

R.H.

1шт.

For Use With Metal Rotary Air Screen

1шт.

Also Included In Kit 87721403

1шт.

4

86976590

INSERT

8mm Well

21шт.

5

86976968

INSERT,Rivnut, M10 x 1.5 x 19mm OD

10mm Well

2шт.

6

87106648

BOOT

Insulator

2шт.

7

87107418

FASTENER

24шт.

8

140045

BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk

4шт.

9

43140

BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8

4шт.

10

291186

PROTECTION STRIP,9.9mm W

Edging

1шт.

11

322358

BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk

1шт.

12

120104

BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8

1шт.

13

86979986

WASHER,0.34" ID x 1.25" OD x 0.06" Thk

1шт.

14

87284670

SUPPORT

1шт.

15

9706690

NUT,M8 x 1.25, Cl 8

4шт.
