1
87281239
PULLEY,275mm OD
Dual, Grooved
1шт.
3000 RPM
1шт.
2
170066
KEY,14mm W x 50mm OAL x 9mm Thk
1шт.
3
84073172
WASHER,13mm ID x 60mm OD x 12mm Thk
1шт.
4
140046
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
6шт.
5
9706717
BOLT,Hex, M12 x 1.75 x 70mm, Cl 8.8
1шт.
6
87510526
PULLEY,185mm OD
1шт.
7
1345226C1
BALL BEARING,80mm ID x 125mm OD x 22mm W
2шт.
8
87510529
SPACER,114.3mm ID x 124.5mm OD x 11mm L
1шт.
9
388294
SNAP RING,M125 x 4mm Thk, Internal
1шт.
10
87510527
HUB
Hub
1шт.
11
86976370
BALL BEARING,34.92mm ID x 72mm OD x 17mm W
1шт.
12
47067
RETAINER COLLAR,34.92mm ID x 56.33mm OD x 17.46mm Thk
1шт.
13
131692
SNAP RING,2.8" ID x 3" OD x 0.095" Thk, External
3" Free OD
1шт.
14
87282629
SPACER
1шт.
15
87283584
COLLAR,36T
Shifter
1шт.
16
87283586
PULLEY,467.7mm OD
1шт.
16
87325137
PLATE
1шт.
16
87283587
GEAR,36T
1шт.
16
14306721
HEX SOC SCREW,M8 x 48mm, Cl 8.8
1шт.
17
87107341
BUSHING,34.9mm ID x 74.6mm Thk
1шт.
18
87485
KEY,50.8mm OAL x 7.96mmThk
Square, 5/16" x 2"
2шт.
19
86517680
V-BELT,3 Rib, 3045mm Nominal Length
3 HB
1шт.
20
86976208
V-BELT,3 Rib, 2720mm Nominal Length
1шт.
3000 RPM
1шт.
21
9635884
BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5
3шт.
22
9706687
BOLT,M12 x 1.75 x 30mm, Cl 8.8
4шт.
23
87283582
RETAINER,119.253mm ID x 125.603mm OD x 1.829mm Thk
Ring
1шт.
25
87337454
RETAINER
Series RR, #256
1шт.
26
87283581
PLATE,125.25mm ID x 200mm OD x 3.025mm Thk
1шт.
27
87283583
COMPRESSION SPRING,12.44mm ID x 31.75mm Free Length
3шт.
28
87283580
RING,131.25mm ID x 15mm Thk
Retainer
1шт.
29
87038215
BALL,10mm OD, Gr 200
10mm, GR 200, SS
3шт.
30
87283579
COLLAR,36T
Shift
1шт.
31
87019103
SET SCREW,M6 x 10mm
HSH, M6 x 1 x 10
7шт.
32
87510844
HUB ASSY.
1шт.
