1
87107122
BRACKET
1шт.
2
27317
WASHER,26mm ID x 51mm OD x 1.17mm Thk
(Shim)
1шт.
3
86976292
SPACER
2шт.
4
86976291
SWINGING DRAWBAR
Idler; Includes: Ref. 22(2)
1шт.
5
84072441
IDLER,180mm OD
1шт.
6
370011
CIRCLIP,M52 x 2mm Thk, Internal
2шт.
7
84057966
BALL BEARING,25mm ID x 52mm OD x 15mm W
2шт.
8
84057817
BUSHING,16.5mm ID x 32mm OD x 53.8mm L
1шт.
9
120093
BOLT,M16 x 2.0 x 90.18mm, Cl 8.8
1шт.
10
140048
BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk
1шт.
11
84073172
WASHER,13mm ID x 60mm OD x 12mm Thk
1шт.
12
9706687
BOLT,M12 x 1.75 x 30mm, Cl 8.8
1шт.
13
86975966
ROD,501.5mm OAL
1шт.
14
390040
COTTER PIN,10mm OD x 39mm L
1шт.
15
9820489
WASHER
M10
1шт.
16
130003
COTTER PIN,3mm OD x 30mm OAL
1шт.
17
86560521
PIVOT,13mm ID x 50mm OD x 25.4mm Thk
1шт.
18
86596885
INDICATOR
1шт.
19
84814905
SPRING
1шт.
20
140018
WASHER,13.5mm ID x 24mm OD x 2.5mm Thk
1шт.
21
412126
NUT,M12 x 1.75
, Serial Range: --
1шт.
22
84057311
BUSHING,25mm ID x 28mm OD x 20mm L
2шт.
