(4-04) - STEERING COLUMN HARNESS

Запчасти Case IH 1670 (4-04) - STEERING COLUMN HARNESS (06) - ELECTRICAL

Схема запчастей Case IH 1670 - (4-04) - STEERING COLUMN HARNESS (06) - ELECTRICAL
10
5
12
16
12
12
14
8
13
15
11
9
17
14
17
14
9
14
10
16
7
13
3
16
6
15
11
17
4
4
13
1
2
5
12
13
3
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

91822C3

HARNESS

- steering column

1шт.

2

200557H1

BULB,C2V, #1815, 14V

- lamp, No. 1815, if used

4шт.

2

26069R1

BULB

- lamp, No. 192, if used

4шт.

3

245513C1

SWITCH

- dimmer, if equipped

1шт.

5

1987422C1

SWITCH

- turn signal (Replaces switch 131066C91)

1шт.

6

131107C1

SWITCH

- neutral start

1шт.

7

425-158

JAM NUT,Jam, 1/2"-20, G5

2шт.

8

1327674C1

BRACKET

ANGLE - switch mounting

1шт.

9

135270

SERRATED SCREW,5/16" - 18 x 3/4"

- slotted truss head, 5/16 NC x 3/4 inch, if used

4шт.

9

409-7516

BOLT,Hex Flg, 5/16" - 18 x 1", Spcl

If used Hex Flg, 5/16"-18 x 1", Serr

4шт.

10

231-5145

SERRATED NUT,Flg, USR, 5/16"-18

NUT - hex serrated flange, 5/16 inch NC

6шт.

11

363444R1

CLAMP,J, 9/16" Insul, 3/8" Bolt

- retaining

6шт.

12

245635C1

SWITCH

- unloader tube control

1шт.

13

340-10812

SCREW,Cross Pan Hd, #8-32 x 3/4"

- machine, pan Phillips, No. 8 NC x 3/4 inch (Replaces screw 26281R1 )

3шт.

16

453453C1

SWITCH

- push button, horn

1шт.

17

411949C91

HORN

- 12 volt, low note (Replaces horn 166166R1)

1шт.
