Запчасти Case IH 2555 (09A-24) - MOISTENER STAND (13) - PICKING SYSTEM

1990262C1

PACKAGE,SERVICE

Left Hand, Consists Of 1 - 19, Not Available As An Assembly, Order Components 1 - 19

1шт.

1990263C1

PACKAGE,SERVICE

Right Hand, Consists Of 1 - 19, Not Illustrated, Not Available As An Assembly, Order Components 1 - 19

1шт.

1

1982682C1

SUPPORT

Left Hand

1шт.

1a

1982683C1

SUPPORT

Right Hand, Not Illustrated

1шт.

2

261-84516

SELF-TAP SCREW,Cross Pan Hd, #10 x 1"

No. 10 NF x 1

3шт.

3

492-11010

LOCK WASHER,#10

3шт.

4

1349998C1

CUP

Water Distributor

1шт.

5

1982416C1

PLATE

1шт.

6

1338720C2

PAD

18шт.

7

214500C2

SUPPORT

Moistener Pad

18шт.

8

310-1518

BOLT,Hex, 5/16" - 18 x 1-1/8" , Gr 8

5/16 x 1-1/8;8

18шт.

9

496-11034

WASHER,11/32" x 11/16" x 1/16", HDN

18шт.

12

1329244C1

SHIELD

1шт.

13

413-512

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

3шт.

14

492-11031

LOCK WASHER,5/16"

3шт.

15

425-105

NUT,5/16"-18, G5

3шт.

16

669838R1

SPRING CLIP

1/4

36шт.

18

109261A1

TUBE,4.06 mm ID, 6.35 mm OD, 102 mm Length

102 mm (4 in), No. 1, Cut From 670199R1

1шт.

18

670201R1

TUBE,0.25" OD, 5.6" Length

152 mm (6 in), No. 2, Cut From 670199R1

1шт.

18

670202R1

TUBE,0.25" OD, 7.4" Length

178 mm (7 in), No. 3, Cut From 670199R1

1шт.

18

670203R1

TUBE,0.25" OD, 9.1" Length

229 mm (9 in), No. 4, Cut From 670199R1

1шт.

1990262C1

PACKAGE,SERVICE

Left Hand, Continued From Previous Page

1шт.

1990263C1

PACKAGE,SERVICE

Right Hand, Continued From Previous Page, Not Illustrated

1шт.

18

670204R1

TUBE,0.25" OD, 11" Length

279 mm (11 in), No. 5, Cut From 670199R1

1шт.

18

670205R1

TUBE,0.25" OD, 12.9" Length

330 mm (13 in), No. 6, Cut From 670199R1

1шт.

18

670206R1

TUBE,0.25" OD, 14" Length

356 mm (14 in), No. 7, Cut From 670199R1

1шт.

18

670207R1

TUBE,0.25" OD, 15.6" Length

406 mm (16 in), No. 8, Cut From 670199R1

1шт.

18

670208R1

TUBE,0.25" OD, 17.4" Length

432 mm (17 in), No. 9, Cut From 670199R1

1шт.

18

670209R1

TUBE,0.25" OD, 19.1" Length

483mm (19 in), No. 10, Cut From 670199R1

1шт.

18

670210R1

TUBE,0.25" OD, 20.9" Length

533 mm (21 in), No. 11, Cut From 670199R1

1шт.

18

670211R1

TUBE,0.25" OD, 22.6" Length

584 mm (23 in), No. 12, Cut From 670199R1

1шт.

18

670212R1

TUBE,0.25" OD, 24.4" Length

610 mm (24 in), No. 13, Cut From 670199R1

1шт.

1990262C1

PACKAGE,SERVICE

Left Hand, Continued From Previous Page

1шт.

1990263C1

PACKAGE,SERVICE

Right Hand, Not Illustrated, Continued From Previous Page

1шт.

18

670213R1

TUBE,0.25" OD, 26.2" Length

660 mm (26 in), No. 14, Cut From 670199R1

1шт.

18

672476R1

TUBE,0.25" OD, 28.4" Length

711 mm (28 in), No. 15, Cut From 670199R1

1шт.

18

672477R1

TUBE,0.25" OD, 30.2" Length

762 mm (30 in), No. 16, Cut From 670199R1

1шт.

18

672478R1

TUBE,0.25" OD, 32" Length

813 mm (32 in), No. 17, Cut From 670199R1

1шт.

18

672479R1

TUBE,0.25" OD, 32.9" Length

838 mm (33 in), No. 18, Cut From 670199R1

1шт.

19

L18337

CABLE TIE,9.95"-12.1" lg

CABLE STRAP 15 in

1шт.

23

1982745C2

ADJUSTING PLATE

Adjusting, Front

1шт.

24

1982747C2

ADJUSTING PLATE

Adjusting, Rear

1шт.

25

413-512

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

4шт.

26

492-11031

LOCK WASHER,5/16"

4шт.

27

495-11034

WASHER,5/16", SAE

(11/32 x 11/16 x 1/16")

4шт.

28

1338549C1

COVER

Water Distribution

1шт.

29

413-820

BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5

2шт.

30

80679

LOCK WASHER,1/20.507 CST ZND

2шт.

31

396-41053

WASHER,13.49mm ID x 31.75mm OD x 5.05mm Thk

2шт.

32

229814A1

SUPPORT

Left Hand

1шт.

32a

229815A1

SUPPORT

Right Hand, Not Illustrated

1шт.

33

409-7616

BOLT,Hex Flg, 3/8" - 16 x 1", Spcl

6шт.

34

95-81085

WASHER,13/32" x 1" x .179"

6шт.

35

231-5146

FLANGE NUT,3/8"-16

6шт.

36

411-636

CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 2 1/4", Gr 2

3/8 x 2-1/4; 2

2шт.

37

425-146

JAM NUT,3/8" - 16, Gr 5

4шт.
