Запчасти Case IH 1370 (350) - DRAFT CONTROL LINKAGE LEVER (09) - CHASSIS/ATTACHMENTS

1

A64430

LEVER

- follow up, draft control

1шт.

2

41-12

PLUG,Exp, 3/4"

- lever, 3/4" expansion type

1шт.

3

F62075

O-RING,0.139" Thk x 0.734" ID, -210, Cl 5, 75 Duro

- lever (3/4 x 1 x 1/8")

1шт.

4

A63447

GASKET

- bushing

1шт.

5

A64429

BUSHING

- follow up lever

1шт.

6

B18208

SNAP RING,#100, Ext

follow up lever #100, Ext

1шт.

7

REF

INSTRUCTION

LINKAGE ASSEMBLY - sensing (See Figure 352)

1шт.

8

A65553

GASKET

- linkage, Serial Range: housing-trans.

1шт.
