1
709252R1
WASHER
BULL GEAR RETAINING
2шт.
28-1228
BOLT,Hex, 3/4" - 16 x 1-3/4", Gr 8
SCREW, 3/4-16 x 1-3/4 C-Z HEX-HD CAP
2шт.
103326
LOCK WASHER,3/4"
WASHER, LOCK, 3/4"
2шт.
2
3044031R1
GEAR WHEEL
GEAR, BULL (48T)
2шт.
3042081R1
SHIM
BULL GEAR
1шт.
3
703913R3
GASKET,0.79mm Thk
REAR AXLE CARRIER
2шт.
4
701067R1
RING
CIRCLIP, 130 MM BORE
2шт.
5
973550R91
BEARING ASSY,2.3622" ID x 5.1181" OD x 1.2205"
REAR AXLE INNER BALL
2шт.
6
3043995R1
COLLAR
REAR AXLE
2шт.
7
3043994R1
AXLE CARRIER
CARRIER, REAR AXLE RH
1шт.
7
3043993R1
AXLE CARRIER
CARRIER, REAR AXLE LH
1шт.
179884
BOLT,Hex, 1/2" - 13 x 1 3/8", Gr 5, Full Thd
SCREW, 1/2-13 x 1-3/8 HEX-HD CAP
20шт.
103323
LOCK WASHER,1/2"
WASHER, LOCK, 1/2"
20шт.
8
ST219A
BALL BEARING,65 mm ID x 120 mm OD x 23 mm
BEARING, REAR AXLE OUTER BALL
2шт.
9
703917R92
OIL SEAL
REAR AXLE OIL
2шт.
10
703915R1
WASHER,2.56mm ID x 3.13mm OD x 0.25mm Thk
REAR AXLE FELT
2шт.
11
711197R1
GASKET
REAR AXLE BEARING RETAINER
2шт.
12
751398R11
RETAINER
W/OIL SEAL 703917R92 AND WASHER 703915R1
2шт.
12
703914R11
RETAINER
W/OIL SEAL 703917R92 AND WASHER 703915R1
2шт.
179838
BOLT,Hex, 3/8" - 16 x 7/8", Gr 5, Full Thd
3/8-16 x 7/8 hex-hd cap
8шт.
103321
LOCK WASHER,3/8"
WASHER, LOCK, 3/8"
8шт.
13
3043997R12
CENTER AXLE
AXLE W/EIGHT BOLTS 3047576R1
2шт.
3047575R2
NUT,Wheel, 5/8"-18
REAR WHEEL
16шт.
14
3047576R2
BOLT
REAR WHEEL
16шт.
15
NOT USED
1шт.
16
NOT USED
1шт.
17
NOT USED
1шт.
18
NOT USED
1шт.
19
NOT USED
1шт.
