1
87434362
SHAFT ASSY.
1шт.
2
38-3605
PIN,3/32" x 5/16", Coiled
3шт.
3
D63322
ROLLER BEARING,Needle, 31.75mm ID x 38.1mm OD x 19.05mm W
1шт.
4
144348C1
SNAP RING,Ext Rtng, 66.294mm ID
1шт.
5
87425389
BELLEVILLE SPRING
11шт.
6
87434656
SEAL,63.75mm ID x 67.75mm OD x 5.5mm Thk
Lube
1шт.
8
1286043C1
THRUST WASHER,63.56mm ID x 82.38mm OD x 2.37mm Thk
2шт.
9
572182R1
THRUST BEARING,63.5mm ID x 82.5mm OD x 1.98mm W
1шт.
10
101-11250
SNAP RING,#250, 2.356, Ext
1шт.
11
1285978C1
PINION
39T
1шт.
12
1286052C1
RING,Locking, 98.8mm ID x 106.6mm OD x 4.5mm Thk
1шт.
13
220057A1
GEAR
25T
1шт.
14
1286041C2
SPACER
1шт.
15
1285990C2
PINION
23T
1шт.
18
84986C1
BEARING ASSY,49.21mm ID x 44.48mm W
1шт.
With 10 Bolt Hub
1шт.
18
253485A1
ROLLER BEARING,49.22mm ID x 44.39mm W
1шт.
With 12 Bolt Hub
1шт.
19
NNA40435
BEARING CUP,103.2mm OD x 36.51mm W
1шт.
With 10 Bolt Hub
1шт.
19
253486A1
BEARING CUP,103.2mm OD x 36.41mm W
1шт.
With 12 Bolt Hub
1шт.
20
1286042C1
THRUST WASHER,57.21mm ID x 76.05mm OD x 2.37mm Thk
4шт.
21
87012543
THRUST BEARING,57.15mm ID x 76.2mm OD x 1.98mm W
2шт.
22
87439841
GEAR
54T
1шт.
23
1286077C1
RING,74.96mm ID x 78mm OD x 2.28mm Thk
1шт.
24
1286081C1
O-RING,1.78mm Thk x 69.57mm ID, -39, 60 Duro
1шт.
25
242491A5
PISTON
1шт.
26
1286079C1
RING,128.96mm ID x 132mm OD x 2.28mm Thk
1шт.
27
1286083C1
O-RING,1.78mm Thk x 120.37mm ID, -48, 60 Duro
1шт.
31
87738316
DISC,107mm ID x 158mm OD x 2.01mm Thk
Separator
1шт.
32
86990276
DISC,98.63mm ID x 141mm OD x 1.95mm Thk
Friction
15шт.
33
92934C2
DISC
Separator
14шт.
34
1342645C3
CLUTCH DISC
CLUTCH DISK
1шт.
35
1285996C1
SNAP RING,151mm OD, Internal
1шт.
36
1286028C2
RING,109.41mm ID x 113.41mm OD x 2.87mm Thk
2шт.
37
297418A2
SEALING RING,Locking, 105.68mm ID x 113.05mm OD x 3.68mm Thk
2шт.
39
80907C1
NEEDLE BEARING,Needle, 57.15mm ID x 66.7mm OD x 25.4mm W
2шт.
40
93269C1
SPACER,62.45mm ID x 66.48mm OD x 12.68mm L
1шт.
41
1286038C2
SPACER
1шт.
42
287679C1
BEARING ASSY,50.8mm ID x 26.91mm W
1шт.
43
1968297C1
BEARING CUP,47.62 mm ID x 111.15 mm OD x 30.36 mm
1шт.
44
87435631
CAGE
Inc. 45
1шт.
45
1345888C1
PLUG
1шт.
47
613-10030
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd
4шт.
50
1286066C1
SHIM,149mm ID x 180mm OD x 0.08mm Thk
2шт.
50
1286067C1
SHIM,149mm ID x 180mm OD x 0.1mm Thk
2шт.
50
1286068C1
SHIM,149mm ID x 180mm OD x 0.13mm Thk
2шт.
50
1286069C1
SHIM,149mm ID x 180mm OD x 0.3mm Thk
2шт.
50
1286070C1
SHIM,149mm ID x 180mm OD x 0.76mm Thk
2шт.
