Запчасти Case IH MAXXUM 115 (35.204.BJ[02]) - VAR - 394835, 743686, 743733, 758359, 758441 - REMOTE CONTROL VALVE, HOSE (35) - HYDRAULIC SYSTEMS

1

84469388

FLEXIBLE HOSE

Load Sensing for Pump

1шт.

2

47126659

ELBOW,90 Deg, 9/16-18 ORFS x 7/16-20 ORB

ASSY, Incl 3 - 7

1шт.

3

47126658

90 ELBOW,9/16"-18 ORFS x 7/16"-20

ASSY, Incl 4 - 6

1шт.

4

NSS

NOT SOLD SEPARAT

Elbow, Incl in 3

1шт.

5

5185509

O-RING,1.78mm Thk x 7.66mm ID, 85 Duro

1шт.

6

5185507

O-RING,8.92mm ID x 1.83mm Width

1шт.

7

47126655

FILTER STRAINER

1шт.

8

86593173

HYD CONNECTOR,9/16"-18 ORFS x M12 x 1.5 ORB

ASSY, Incl 9 - 11

1шт.

9

NSS

NOT SOLD SEPARAT

Connector, Incl in 8

1шт.

10

86598098

O-RING,2.2mm Thk x 9.3mm ID, Cl 6, 90 Duro

1шт.

11

9825770

O-RING,0.07" Thk x 0.301" ID, -11, Cl 6, 90 Duro

1шт.
