(25.102.AT[04]) - VAR - 330429, 330430 - CL.4 - 4WD FRONT AXLE - DIFFERENTIAL LOCK LINES

Запчасти Case IH MAXXUM 140 (25.102.AT[04]) - VAR - 330429, 330430 - CL.4 - 4WD FRONT AXLE - DIFFERENTIAL LOCK LINES (25) - FRONT AXLE SYSTEM

Схема запчастей Case IH MAXXUM 140 - (25.102.AT[04]) - VAR - 330429, 330430 - CL.4 - 4WD FRONT AXLE - DIFFERENTIAL LOCK LINES (25) - FRONT AXLE SYSTEM
8
31.104.ar 03
7
4
31.104.ar 06
9
10
1
5
3
home
11
21.111.ac
2
31.104.ar 07
31.104.ar 01
21.112.ac
6
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

84473416

TUBE

1шт.

2

10519421

WASHER,6.4mm ID x 11.95mm OD x 1.6mm Thk

1шт.

3

82036783

FLEXIBLE HOSE,9.53mm ID x 580mm L, SAE 100R2

1шт.

4

87543759

TUBE,8 mm ID x 10 mm OD x 650, 555 mm L

1шт.

5

86977726

BOLT,Hex, M6 x 12mm, Cl 8.8

1шт.

6

84426961

BRACKET

1шт.

7

16050621

SCREW,Hex, M6 x 30mm, Cl 8.8, Full Thd

2шт.

8

14496401

WASHER,M6.4 x 12.00mm x 1.60mm

2шт.

9

82029228

CLAMP,2 Hoses

1шт.

10

84332672

BRACKET

1шт.

11

87317792

SUPPORT

1шт.
