1
255426A2
SHAFT
1шт.
Without Mechanical Front Drive
1шт.
2
199320A1
SHAFT
1шт.
With Mechanical Front Drive
1шт.
3
813-10050
BOLT,Hex, M10 x 1.5 x 50mm, Cl 8.8
M10 x 50; 8
6шт.
4
218-5351
HYD CONNECTOR,3/4"-16, 37 Degree x 9/16"-18, O-Ring
3/4 fl x 9/16 Or, Inc. 5
1шт.
6
124306A1
TUBE,12.7 mm OD, 469, 181 mm Length
1шт.
10
1997881C1
SHIELD
1шт.
11
806-8016
BOLT,Hex, M8 x 1.25 x 16mm, Cl 10.9
M8 x 16; 10.9
3шт.
12
630694C1
BEARING CONE,64.98mm ID x 105mm OD x 24mm W
2шт.
13
86577049
TAPERED BEARING,65mm ID x 105mm OD x 24mm W
2шт.
14
222856A1
PINION
1шт.
15
101-21412
SNAP RING,#412, 4.430", Int
2шт.
16
138121A1
SHIM,65mm ID x 80mm OD x 0.2mm Thk
1шт.
16
1997893C1
SHIM,65.5mm ID x 80mm OD x 0.51mm Thk
1шт.
16
1997894C1
SHIM,65.5mm ID x 80mm OD x 0.56mm Thk
1шт.
16
1997895C1
SHIM,65.5mm ID x 80mm OD x 0.64mm Thk
1шт.
17
1277309C1
WASHER,65.25mm ID x 77mm OD x 3mm Thk
1шт.
18
1997891C1
SNAP RING
1шт.
19
117853A1
HOUSING,242mm OD x 58mm W
1шт.
20
198853A1
SEALING RING
SEALRING
1шт.
23
238-5014
O-RING,0.07" Thk x 0.489" ID, -14, Cl 5, 75 Duro
1шт.
24
436285A1
COVER
Inc. 25 - 28
1шт.
25
511-1070
BALL,7mm Dia
7 mm
1шт.
26
221576A1
PLUG,Hex Soc, M14 x 1.5, ORB
Incl. 27
1шт.
27
637-63113
O-RING,2.2mm Thk x 11.3mm ID, Cl 6
1шт.
28
255404A3
SPRING
1шт.
29
628-10030
BOLT,Hex, M10 x 1.5 x 30mm, Cl 10.9, Full Thd
4шт.
30
828-10070
BOLT,Hex, M10 x 1.5 x 70mm, Cl 10.9
2шт.
31
896-12016
WASHER,17.5mm ID x 30mm OD x 4mm Thk
2шт.
32
198336A1
BOLT
2шт.
33
238-5114
O-RING,0.103" Thk x 0.612" ID, -114, Cl 5, 75 Duro
2шт.
40
195066A3
CARRIER
1шт.
41
198502A1
RING, SNAP
RING SNAP
2шт.
42
195068A2
PLATE
1шт.
43
118421A1
BRAKE DISC,160.91mm ID x 222.25mm OD x 5.75mm Thk
5шт.
44
195067A2
CLUTCH PLATE,174.5mm ID x 235mm OD x 3.5mm Thk
5шт.
45
195069A2
PISTON
1шт.
46
238-7169
O-RING,0.103" Thk x 7.487" ID, -167, Cl 7, 75 Duro
1шт.
47
198684A1
SEALING RING
SEALRING
1шт.
48
238-7175
O-RING,0.103" Thk x 8.897" ID, -175, Cl 7, 75 Duro
9 ID x 3/32
1шт.
49
198685A1
SEALING RING
SEALRING
1шт.
50
195118A1
SPRING WASHER
6шт.
51
284935A1
BACKING PLATE
1шт.
52
198501A1
RING, SNAP
RING SNAP
1шт.
55
296409A3
PLATE
1шт.
Without Mechanical Front Drive
1шт.
56
311910A1
PLUG
1шт.
57
296268A1
SHIELD
1шт.
With Mechanical Front Drive
1шт.
58
806-6010
BOLT,Hex, M6 x 10mm, Cl 10.9
M6 x 10; 10.9
4шт.
59
782-84413
SELF-TAP SCREW,Hex Flg, M4.8 x 1.6 x 13mm
M4,8 X 13
3шт.
5
237-6006
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
1шт.
