(55.518.040) - WINDSHIELD WASH RESERVOIR, WATER PUMP, LINE

Запчасти Case IH OPTUM 270 CVT (55.518.040) - WINDSHIELD WASH RESERVOIR, WATER PUMP, LINE (55) - ELECTRICAL SYSTEMS

Схема запчастей Case IH OPTUM 270 CVT - (55.518.040) - WINDSHIELD WASH RESERVOIR, WATER PUMP, LINE (55) - ELECTRICAL SYSTEMS
90.150.110
3
3
5
2
1
4
2
55.510.010
90.150.030
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

47695190

WIPER MOTOR,2 SPD, 90DEG, EMC

2 SPD, 90 Deg.

1шт.

2

14496501

WASHER,8.4mm ID x 17mm OD x 1.6mm Thk

4шт.

3

120104

BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8

4шт.

4

47695191

WIPER ARM,Single, 550mm L

1шт.

5

82030990

WIPER BLADE,Single, 550mm L

1шт.

5

47725333

WIPER BLADE,560mm L

560mm

1шт.
