(37.100.0601) - SLIDER TOW HOOK WITH FIXED COUPLING (D3 TYPE) (VAR.743225)

Запчасти Case IH PUMA 230 (37.100.0601) - SLIDER TOW HOOK WITH FIXED COUPLING (D3 TYPE) (VAR.743225) (37) - HITCHES, DRAWBARS & IMPLEMENT COUPLINGS

Схема запчастей Case IH PUMA 230 - (37.100.0601) - SLIDER TOW HOOK WITH FIXED COUPLING (D3 TYPE) (VAR.743225) (37) - HITCHES, DRAWBARS & IMPLEMENT COUPLINGS
5
3
2
home
6
4
1
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

84177394

HITCH BRACKET

ASSY, Contains Ref. 4,5

1шт.

2

84177410

TRAILER HITCH

ASSY, Contains Ref. 3

1шт.

3

84191356

CLEVIS PIN

1шт.

4

84191360

COVER

1шт.

5

84191361

MOUNTING PLATE

1шт.

6

16220874

BOLT,Hex, M18 x 1.5 x 45mm, Cl 12.9

8шт.
