(01A-03) - HYDRAULICS- POWER SHIFT TRANSMISSION AND PTO CLUTCH LUBE WITH ACCUSTEER

Запчасти Case IH STEIGER 335 (01A-03) - HYDRAULICS- POWER SHIFT TRANSMISSION AND PTO CLUTCH LUBE WITH ACCUSTEER (00) - PICTORIAL INDEX

Схема запчастей Case IH STEIGER 335 - (01A-03) - HYDRAULICS- POWER SHIFT TRANSMISSION AND PTO CLUTCH LUBE WITH ACCUSTEER (00) - PICTORIAL INDEX
06-26
7
11
1
9
06-14
5
06-13
08-02
3
06-13
06-26
06-26
8
08-01
06-26
06-26
4
2
10
08-03
6
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

HOSE, Transmission, Regulator Valve Supply, See Figure 06-26

1шт.

2

HOSE, Outlet, Pump To Filter, See Figure 06-26

1шт.

3

FILTER, Left-Hand, See Figure 08-03

1шт.

4

COOLER, Hydraulic Oil, See Figure 08-02

1шт.

5

TUBE, Transmission, Pump Supply, See Figure 06-26

1шт.

6

HOSE, Cooler Supply and Outlet, See Figure 08-01

1шт.

7

VALVE ASSY., PTO Control, See Figure 06-14

1шт.

8

TUBE, PTO Valve, Pressure Supply, See Figure 06-13

1шт.

9

TUBE, Transmission, Regulator Valve Supply, See Figure 06-26

1шт.

10

TUBE, Outlet, Pump To Filter, See Figure 06-26

1шт.

11

TUBE, PTO Valve, Lube Supply, See Figure 06-13

1шт.
