(01A-06) - HYDRAULICS - ELECTRONIC HITCH CIRCUIT

Запчасти Case IH STEIGER 335 (01A-06) - HYDRAULICS - ELECTRONIC HITCH CIRCUIT (00) - PICTORIAL INDEX

Схема запчастей Case IH STEIGER 335 - (01A-06) - HYDRAULICS - ELECTRONIC HITCH CIRCUIT (00) - PICTORIAL INDEX
1
5
6
3
7
08-37
08-37
08-37
08-37
08-38
08-37
08-37
08-38
4
2
1
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

CYLINDER, Three-Point Hitch Lift, See Figure 08-38

1шт.

2

HOSE, Cylinder Supply, Right-Hand, See Figure 08-37

1шт.

3

HOSE, Cylinder Return To Tank, See Figure 08-37

1шт.

4

TUBE, Return From Hitch Valve, See Figure 08-37

1шт.

5

HOSE, Return To Tank, See Figure 08-37

1шт.

6

HOSE, Cylinder Supply, Left-Hand, See Figure 08-37

1шт.

7

HOSE, Cylinder Return, Left-Hand, See Figure 08-37

1шт.
