(01A-10) - HYDRAULICS - CHARGE PUMP AND BRAKE CIRCUIT WITHOUT ACCUSTEER

Запчасти Case IH STEIGER 335 (01A-10) - HYDRAULICS - CHARGE PUMP AND BRAKE CIRCUIT WITHOUT ACCUSTEER (00) - PICTORIAL INDEX

Схема запчастей Case IH STEIGER 335 - (01A-10) - HYDRAULICS - CHARGE PUMP AND BRAKE CIRCUIT WITHOUT ACCUSTEER (00) - PICTORIAL INDEX
3
21
07-03
07-05
07-07
07-05
07-07
07-05
07-07
07-05
07-07
07-05
08-09
07-05
08-20
08-17
08-20
07-05
07-07
07-07
07-03
07-03
07-02
08-17
08-11
07-09
08-05
08-04
07-03
08-16
07-05
14
8
6
1
20
18
13
7
15
9
12
10
19
16
16
08-26
11
4
2
5
17
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

PUMP, Gear, See Figure 08-26

1шт.

2

TUBE, Gear Pump Supply, Standard Hydraulics, See Figure 08-17

1шт.

2

TUBE, Gear Pump Supply, High Output Hydraulics, See Figure 08-20

1шт.

3

HOSE, Gear Pump to Charge Pressure Tube, Standard Hydraulics, See Figure 08-17

1шт.

3

HOSE, Gear Pump to Charge Pressure Tube, High Output Hydraulics

1шт.

4

TUBE, Charge Pressure, To Filter, See Figure 08-09

1шт.

5

FILTER, Main Hydraulic (Below Battery), See Figure 08-04

1шт.

6

HOSE, Service Brake Line, See Figure 07-03

1шт.

7

HOSE, Tow Valve Supply, To Rear Axle Park Brake, See Figure 07-05 & 07-07

1шт.

8

HOSE, Tow Valve Supply, To Front Axle Park Brake, See Figure 07-05 & 07-07

1шт.

9

VALVE, Regulator, See Figure 08-11

1шт.

10

HOSE, Regulator Output to Brake Valve, See Figure 07-05 & 07-07

1шт.

11

VALVE, Brake, See Figure 07-02

1шт.

12

HOSE, Brake Valve, Return To Tank, See Figure 07-05 & 07-07

1шт.

13

HOSE, Service Brake, To Rear Axle, See Figure 07-03

1шт.

14

HOSE, Service Brake, To Front Axle, See Figure 07-03

1шт.

15

SOLENOID, Differential Lock, Used In Differential Lock Applications, See Figure 07-09

1шт.

16

TUBE, Differential Lock, Used In Differential Lock Applications, See Figure 07-05

1шт.

17

TUBE, Regulator Output to Brake Valve, See Figure 07-05 & 07-07

1шт.

18

TUBE, Brake Valve Return to Tank, See Figure 07-05 & 07-07

1шт.

19

TUBE, Service Brake Line, See Figure 07-03

1шт.

20

TUBE, Return to Tank, See Figure 08-05

1шт.

21

TANK, Hydraulic, See Figure 08-16

1шт.
